NL1
NEPTUNE L380 B is a 260W laser light source waterproof beam moving head light. 230mm super large light-emitting lens, 1° extremely narrow beam angle, close to parallel beam, beam diameter is only 0.87 meters at a distance of 100 meters, and the illuminance is about 20000lux. The beam is stronger and sharp edges, and the beam formed by high-efficiency optics is like a bright beam. lt is suitable for urban landscape, cultural tourism lighting, concerts, theme parks and other places.
DETAILS
PRODUCT PARAMETERS
Optical system
Light source
260W laser light source
Angle
1.0°
Control System
Pan/Tilt rotation
540°/270°(8-16bit)
Dimmer
0-100%16Bit
Cooling
Forced Convection
Control
DMX512、RDM、ARTNET、SACN,W-DMX(optional、Web Server
Display
On Board Control, Custom Mode, 0-25Hz Strobe
Con Personality
STANDARD(17CHS)、BASIC(13CHS)、 EXTEND(19CHS)
Effect synthetic system
Static Gobo
Static gobo whee(l 29 gobos+white)
Colors
One color wheel (19 color+white, rainbow-flow effect)
CTO+CTB
3000K/8000K CTO+CTB
Prism
One 16 prism, bidirectional rotating; speed can be adjusted
Linear prism
1pcs linear 6F prism,bidirectional rotating, speed can be adjusted
Focus
Motorized linear focus
Frost
1 Frost filter
Appearance
Size
416x358x712mm
Weight
36.9kg
Casing
Magnalium and Die-cast
Electrical Specs
Voltage
AC100-240,50/60Hz
Max.Power
380W
Power Connection
power in
Signal socker
3pin or 5pin in and out, RJ45 in and out
Work Environment
Ambient Temp
-20°C-45°C
IP Rated
IP65
