ILLUMINANCE
T8
The T8 is a high-power LED moving profile with an
efficient optical system combined with an intelligent
electronic zoom of 5°-50°. With X/Y positioning smooth
and accurate, professional color wheel show magic
color effect, gobo wheel switch fast and sensitive, the
effect is more colorful. Professional framing systems
can cut out any polygon. Professional atomizing
mirrors can meet the needs of stage dyeing. The
customized aperture will show the flexibility of the
spot more vividly. This product is specially developed
for theater, cultural hall, multi-function hall, banquet
hall and rental performance venue.
DETAILS
Optical system
Light source
600W
Angle
5°-50
RA
95
illumination
58000Lx@5M
Control System
Pan/Tilt rotation
540°/270°(8-16bit)
Dimmer
Opera dimming effect (0-100% 16Bit dimming)
Cooling
forced air cooling
Control
DMX512、RDM、SACN、ARTNET、W-DMX（optional）
Display
Display board control static, custom mode, 0-25Hz stroboscopic
Special function
Horizontal and vertical can be set to close in operation, and horizontal and vertical reversal can be set
tunnel mode
BASIC、STANDARD、EXTEND
Effect synthetic system
Rotating Gobo
7 rotating gobos+open, gobo-flow effect,gobo shaking effect, Bi-direction rotation
Static Gobo
10 gobo+open, gobo flow effect，pattern shaking effect
Colors
7 colors+open,rainbow-flow effect
CMYK
CMY，CTO
Framing system
4 shutters, smooth cutting, each cutting direction and Angle can closed, and the entire cutting module can be rotated ±90° be independently controlled;The single shutters can be completely
prism
One 5-facet prism, reversible rotation, adjustable speed
Animation Wheel
Bi-directional rotation,Speed adjustfable
Iris
5-100% linear aperture adjustment with macro function
focus
With linear focus function
zoom
With linear zoom function
Frost
A frost
Certification
CE
Work Environment
Ambient Temp
0℃-45℃
IP Rated
IP20
